Plating rectifier specification and parameter:

Plating rectifier Input voltage

3 phase 380V/415V/440V/600V 50-60Hz,

Output voltage

6V/12V/15V/18V/24V/36V/48V optional or according to customers’ request

Output current

0-750A (Random optional)

Voltage stability

≤1%

Current stability

≤1%

Ripple factor

1%-2%

Efficiency

≥90%

 Stabilization mode

Current stabilization/Voltage stabilization (Switchable easily)

Adjustment range

Voltage/Current from 0-100% continuously adjustable within rated range

Cooling system

Air cooling/Water cooling/Oil cooling

Control method

Manual/PLC

Display contents

Voltage meter/Current meter/Working/Over temp/Error, etc..

Protection method

Input over-voltage/Under-voltage/Over current/Output short/Over heating self protection lack of phase etc..

Operating temperature

-20-50℃

Ambient temperature

-30-65℃

Ambient humidity

≤90%

Working loading

Full capacity operation, more than 1,000 meters above sea level, reduced load operation
